Arcade-GameStaon
6. Assembly instrucons
Step 4 | Installaon of the joyscks
Next step is mounng the joysck. Unscrew the head of the joysck and take o the
black plate.
To mount the joysck, take four screws [A] and washers [H] and sck them through the
case from above.
Place the joysck from below on the screws, take a washer [H], place it on the screw,
take a nut [F] and screw it ght. Repeat this process with the other three screws.
Head
Plate
