Arcade-GameStaon
6. Assembly instrucons
Its up to you which of the two signal-plugs you are going to use. But please note that
there is an excepon for the buon with the player-logo:
The inner second signal-plug is going to be used.
The signal-plug 1 and the ground-plug are remaining—x those with a cable e.
There are also contacts beneath the joysck. The two ground-plugs are connected this
way on the curved contacts :
Signal-plug 2
Ground
Signal-plug 1
Ground 2
Signal-plug 1
Signal-plug 2
Ground 1
