Arcade-GameStaon
6. Assembly instrucons
The signal-plugs have to be connected this way:
Repeat this process with the other four contacts of the joysck.
Step 6 | Installaon of the potenometers signalcable and the RGB-LEDs
Next, take one of the two cables which have a white connector on both sides and
connect it to the connecon of the potenometer.
