Arcade-GameStaon
6. Assembly instrucons
Step 8 | Assembling the Raspberry-Pi-control-center
To mount the Raspberry Pi, take the spacers [J] rst. Sck them through the four yellow
borderer holes on the board. Screw another four spacers [E] on the spacers from below
aerwards.
Mount the baseboard with four screws [D].
