Arcade-GameStaon
7. Service
Linker Kit Board with Real-Time-Clock
Based on a RTC-Chip DS1307, which is controlled by I
2
C-Bus. The
chip is powered by a button cell even by a turned off microcontroller-
system.
 RTC-Modul e with I
2
C-Chip DS1307
 Output of date and time (24/12-h-Format) over I
2
C-Bus
 Internal correction-function
Linker Kit Board with temperature sensor
The temperature-sensor creates a voltage, propotional to the tempera-
ture which is analyseable by an µC-ADC-Port.
 Linear temperature-sensor TMP36, range -40 to +150 °C
 Output voltage 0,1 V (-40 °C) to 2,0 V (150 °C)
Linker Kit board with infrared motion-sensor
The motion-sensor can be used to trigger controlling processes (e.g.
to control light or the Raspberry Pis camera).
 Detection angle: 120°
 Capture-range 3 to 6 m, adjustable
 Matching to the Linker-Kit-System for Arduino and Raspberry Pi
Linker Kit board with buzzer
This buzzer can be connected to digital outputs to create a sound. It
can also be connected to an analog pulse-width-modulation output to
create different sounds and effects.
Linker Kit board with light-sensor
The breakout-board is equipped with a light-sensor and a signal
amplifier.
 Analog signal output proportional to the surrounding brightness
