4. DEVICE OVERVIEW
Screen
Keypad
Confirm button
Direction buttons
Rotary Encoder
Output switch
Power supply output
positive terminal
Battery charging
positive terminal
Power supply output/
battery charging: nega-
tive terminal
Micro USB Interface
Second function button
Power button
Quick storage button
Current /Overcurrent protection
value setting
Voltage/ Overvoltage
protection value setting
Input fuse
External temperature sensor interface
Power Source input interface CR1220 battery socket
Output fuse
Fan interface
Communication module interface
4.1. RD6006 / RD6012 Front Panel:
4.2. RD6006 Back:
