To get into this menu you have to navigate in the protocol trigger menu to the
item USB-C PD and then press K1.
1. Current PD mode
2. PPS voltages
3. Actual output voltage
4 Green: Current voltage
White: Supported voltages
Now disconnect the power supply and reconnect it.
With K1/K2 you can adjust the PD voltage.
Keep K1 pressed to change the PPS voltage step size.
Keep K2 pressed to exit the menu.
3.5 PROTOCOL TRIGGER
This menu allows you to initiate a quick charge protocol even if your load
does not have this quick charge function.
ATTENTION! This function increases the output voltage of the USB-C port.
Make sure that your connected load is compatible or remove it.
Keep K2 pressed to enter the menu.
With K2 you can navigate through the menu and with K1 into the
submenus.
With K1 and K2 you can trigger the protocol and adjust the voltage.
Keep K2 pressed to get back.
3.6 SYSTEM SETTINGS
In the system settings you can make various settings, including:
1. Display illumination time
2. Backlight
3. Temperature unit
4. USB connection
5. BT wireless connection
6. Screen rotate
7. CC Pin Pulldown
8. Language
9. Factory settings
Use K2 to navigate through the menu and K1 to select settings.
1 2 3 4 5 6 7 8 9
3.5.1 PD-TRIGGER
4
2
3
1
To Next Page
