Joy-it RB-LEDMatrix User Manual

2. USE WITH THE RASPBERRY PI
2.1 Installing the soware
If you are already using a current Raspberry Pi OS on your Raspberry Pi, you can skip this step and
continue immediately with step 2.2.
Install on your SD card using the „Win32 Disk Imager“ - program the current Raspbian Image, which you
can download under the following link.
2.2 Connecting the module
Place the module on pins 1 to 26 of your Raspberry Pi as shown in the following picture. Note that the
module is placed with the overhang facing the Raspberry Pi.
