Secure Base Using Vehicle Bolt: Replace bolt while

securing the base (j).

Attach Mount to Base: Place mount over base and

secure by turning latch.

Attach Bracket with Bolt & Mount to Base: Replace

the bolt while securing the bracket. Place mount over

base and secure by turning latch.

(j)

(i)

(g)

(h)

(d)

Remove Vehicle Bolt: Remove the bolt from the vehicle.

Mounting Option 1

Secure Base to 180º Bracket: Assemble bracket

according to diagram above. The extended bracket (d, i,

g, h) can be utilized to add additional support. Ensure

connection is tight.

(e)

(j)

(f)

(g)

(c)

Mounting Option 2

Remove Vehicle Bolt: Remove the bolt from the vehicle.

MOUNT INSTALLATION: Mount
