HANDBOOK / KIT INTERFACE
4
If we click on COUNTERS, the following screen will open,
showing all counters. To see values, click on READ.
Short explanation of each COUNTER:
• Version: Software version of the PCB CONTROL part
• Options: Parameter for internal use only.
• Operations: Number of times the cam steps on the
OPEN or CLOSE micro switch.
• Limitations: Number of times the limiter function has
been activated, due to a higher torque than the allowed.
• End Order: Parameter for internal use only.
• Time Error: Number of times the motor has been
stopped, as the OPERATION TIME parameter value has
been overpassed, but the actuator has not reached
either the OPEN or CLOSE position yet. It usually
happens when the declutching lever is in MAN position.
(The user wants to move the actuator manually).
• Power On: Number of times the actuator remains
without Power Supply.
• BSR: Number of times the actuator has been activated
by using the BSR system, due to a Power Supply failure.
This counter won’t work if the BSR system has not
been installed on the actuator before.
To go back to the MENU, click on MAIN MENU.
