ACTUATOR OPERATIONAL STATUS
MODELS: 20, 35, 55, 85, 140, 300
The LED Light provides visual communication between the actuator and the user.
The current operational status is shown by different LED colors.
ON-OFF ACTUATOR
Without power supply
In open position
In close position
Opening
Closing
Torque limiter function on, moving from close to open
Torque limiter function on, moving from open to close
Actuator in MANUAL mode (Exceeded time)
The actuator has stopped (*)
In middle position (for a 3 position actuator only)
(*) Actuator powered on to Open and Close position at the same time.
ACTUATOR OPERATIONAL STATUS
HANDBOOK / J4C SERIES
