Index
ASSEMBLY INSTRUCTIONS - DPS KIT 20/85
KIT COMPONENTS
Element A - 1 Cover
Element B - 1 Plastic column
Element C - 1 DPS positioner PCB
Element D - 2 Sheet metal Fixing screws
Element E - 1 Plastic Fixing screws
* Fill in the document inside the kit, and send it to the fax number or e-mail, shown in the document. The unit is ready
to work.
HANDBOOK / KIT DPS
Very important!
Please follow the instructions step by step. Before connecting “A” plug to the actuator, check that
the voltage is the same as the one specied on the label (carter). To convert a standard (on-off)
J4C electric actuator into a modulating function with positioner, proceed as follows:
A
B
C
D
E
