ASSEMBLY INSTRUCTIONS - BSR KIT 140/300
KIT COMPONENTS
Element A - 1 BSR PCB.
Element B - 2 Battery support.
Element C - 2 Battery pack.
Element D - 3 Sheet metal xing screws.
Element E - 1 Plastic clamp.
* Fill in the document inside the kit, and send it to e-mail: info@jjbcn.com or the fax number (93 871 32 72), shown in
the document.
A
B
D E
C1
C2
Connect 1
Connect 1
Connect 2
Connect 2
Very important!
Please, follow these instructions step by step.If the connector of the battery pack is pluged to the
“BSR” pcb, before arriving to point 4, the pcb could be damaged.
