JMA-5300 series - performance features
Chart Overlay
Chart infomation can be combined with the radar image to
present a complete overview of activity around the vessel.
The radar image is combined with information from
electronic charts. Own and other ship's tracks and AIS
targets can be plotted and waypoints entered.
A significant contribution to safe navigation.
Target enhancement function(TEF)™
Developed exclusivly by JRC, TEF allows better indentifca-
tion of small / weak echos. Equally, coastlines appear with
improved definition.
TEF works by adding pixels to targets displayed on the
radar image and allows a vastly improved degree of
distinguisment between targets.
Sophisticated processing results in a proportional en-
hancement where the relative enhancment of smaller tar-
gets is greater than that applied to larger targets.
TEF is available in three levels-x5, x9 and x17.
Constaview™
All the information gathered by the radar is stored in the
system, therefore switching from one veiw, i.e North-up to
Head-up or Range changes, instantly produces a new,
complete radar image, reflecting the new selection.
Targets that need to be closely followed can easily be
reidentified on the new image. Constaview™ represents a
major contribution to safety and operational flexibilty.
Unique features
JMA-5300 series represents a major advance in Radar technology. The newly delevoped
processing system gives users a range of new features not previously found on this
class of radar.
JMA-5300 series represents a major advance in Radar technology. The newly delevoped
processing system gives users a range of new features not previously found on this
class of radar.
Real-time Head-up mode
Tr ue Trails
Constaview™ refreshes the image
every 16mS. Despite heading
changes trails are always True.
Relative Trails
Traditional technology relies on
several sweeps of the scanner to
redraw the image.
Trails are presented as relative.
Constaview™ Conventional
Radar
sweep
Redrawing
