4－10
JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.5 NAVIGATOR SETTING
4.5 NAVIGATOR SETTING
Set ON or OFF to indicate whether a navigator is connected to this apparatus or
not. Only the navigator set at ON can be used.
Procedures
1) Open the [Service Man Menu] screen.
2) Open the [3.Device Installation] screen according to the operation shown
below.
3) Set ON when a navigator is connected, and set OFF when a navigator is not
connected.
2. Installation Menu
→
9. Next
→
3. Device Installation
Gyro：
Gyro (via gyro interface)
Compass：
Compass (IEC61162 specification)
GPS Compass：
GPS compass made by JRC
LOG：
Log (via gyro interface)
2AXW：
Log over water (IEC61162 specification)
2AXG：
Log over ground (IEC61162 specification)
GPS：
GPS(IEC61162 specification)
To Next Page
