20
Transmission Power: Hi (High) and Lo (Low)
Indicate current Group and current Channel
Frequency: it shows the RF frequency
Battery level: in 5 levels
Sensitivity Value
Low Cut indication
Attenuate Indication
Lock On Statue
For screen display and operation please refer to ''6-5. System
operation setup for Body-Pack transmitter''.
-12dB
IDoff
633.875 MHz
G: 1 C: 11
AT
Hi
LCD displays
9
10
11
12
13
14 15
16
9
10
11
12
13
14
15
16
