WIRELESS MICROPHONE SYSTEM
19
5-3 Body-pack Transmitter // PT-990B(mi)
(1) Turning the transmitter on/o
The on/o switch is located on the top of the transmitter.
(2) Inserting and changing the battery
1. The battery tray is located on the back of the transmitter.
2. Hold on to both belt clip buttons to release it.
3. Insert 2 pieces of UM-3 1.5V batteries. Remember to match correct polarity.
4. Directly slide the belt clip back.
(3) With Lavalier microphone
Attach Lavalier microphone to clothing, tie, lapel, where is the suitable place of sound
pick-up. Plug the mini XLR on the microphone cable into the “MIC. IN” on the body-pack
transmitter.
To Next Page
