30 JUDO QUICKSOFT-DUO
JQS-D Spare Parts
95 Pan-head tapping screw 2.9x16 4 1650173 1
98 Cam wheel 1 1120277 6
99 Thrust bearing plate 1 2200549 16
100 Cylinder head screw M5x45 1 1650251 2
103 Intermediate hose 1 2200596 1
104 Cover seal * 1 1200255 3
105 Injector seal * 1 1200237 8
106 Injector chamber 1 2200487 40
107 Injector chamber cover *** 1 2200556 48
108 IRV adapter *** 1 2200567 32
109 Washer (injector) 3 2201272 1
110 Pan-head tapping screw 2.9x13 2 1609172 1
111 Strain relieving bracket 1 1609114 2
112 HE contactor 1 2200715 51
113 Tool cover 1 2200444 30
114 O-ring 43x3 ** 1 1200187 2
115 Impeller with magnet 1 2201258 33
116 O-ring 13x2.5 1 1200236 1
141 Solenoid valve cable 1 2200714 31
142 Electrode cable 1 2200716 21
148 Flexible hose 1 2200722 170
160 Spare parts kit for solenoid 1 2201463
161 Spare parts kit for drive * 1 2200581 175
162 Spare parts kit for overflow valve **** 1 2200418 64
163 Spare parts kit for pressure reducer *** 1 2200582 88
164 Spare parts kit for controls *** 1 2200579 150
166 Spare parts kit for injector * 1 2200585 30
167 Spare parts kit for water meter 1 2200763 106
1) AU = Accounting unit
Replacement interval
* = 1 year, ** = 2 years, *** = 3 years, **** = 4 years, ***** = 5 years
Item
Name
(Recommended average replacement inter-
val for worn part [*])
No. Order No.
AU
1)
/each
