14
Operation
General Operating Instructions
IMPORTANT: Always position the pitching machine so that two legs are
facing the pitching screen and batter, and one leg is facing back, towards
the operator (Figure 7.)
1. Be sure the control switch is in the “OFF” position.
2. Position the speed dial pointer on the control
panel at MINIMUM (Figure8).
3. Position the rubber pad bracket until the bolt holes line up with lower
bolt holes for baseball, (Figure 6).
4. Connect a 3-wire extension cord (3-prong) into a grounded (3-prong)
110 volt AC outlet (Figure 2).
5. Move control switch to “ON” position.
Figure 9. Control Panel
Figure 8
