Press the bobbin against the
bobbin winding regulator.
7. Push the bobbin back
to the left.
9. Pull the thread into the
groove of the bobbin
case.
6. Depress speed
controller to wind bobbin.
10. Close the hook cover.
Bobbin winding
regulator
Bobbin
winder
[1]
[2]
8
5. Place the bobbin on the
bobbin winding shaft.
Bobbin winding
regulator
Bobbin
winder
HZL-30Z
HZL-60
HZL-30Z
HZL-60
HZL-30Z
HZL-60
HZL-30Z
HZL-60
Cut the thread and take the
bobbin off the shaft.
8. Place the bobbin in
case with thread pulling
off as illustrated.
HZL-30Z
HZL-60
[1]
[2]
Thread [1], place the thread on
the groove [2] and draw thread
to rear of machine.
HZL-30Z
HZL-60
Hook the thread into
the thread guide.
4. Follow threading path into the bobbin winder thread
guide.
Hook the
thread into
the thread
guide.
