L type (thick-thread long-pitch)
The machine performs sewing with consistency with a broader range of needle counts up to #0.
In addition, it achieves the maximum stitch length of 12mm.
A triangular cam has been adopted for the feed rock cam. This
enables consistent sewing with a thread count of up to 0.
The machine comes provided as standard with a handwheel
which is larger than the S type (standard) so as to increase the
material-penetrating force of the needle.
In order to ensure an efficiency of feed (presser foot pressure)
which is larger than that provided by the S type (standard), a
double-coil spring is equipped as standard for the pressure bar
spring.
The maximum stitch length is 12mm for both forward and
reverse feed directions. In addition, the alternating vertical
movement dial is provided as standard.
Excellent operability
The basic performance (specifications) has been dramatically improved
A maximum number of revolutions of
2500sti/min (increased by 25%) is
achieved to increase productivity.
Higher lift
of the presser foot
The presser foot lift is as high as 16mm, allowing the user to
handle the material with ease.
Simple-setting of the amount of
alternating vertical movement
The vertical strokes of the presser foot and walking foot
(alternating vertical movement) can be easily changed using a
large dial mounted on the top surface of the machine head.
In addition the sewing speed is automatically adjusted with the
set value. With this feature, ideal sewing conditions are
maintained at all times.
The machine is able to support a
maximum stitch length of 9mm (12mm
for the L type).
It is now possible to factory-install the
presser foot with a center guide for
2needles at the time of delivery.
16mm
