EN
28
• If the memory cable (RED) is
earthed or connected wrong the
car stereo can be damaged or
impossible to start or switch o.
TECHNICAL DATA
Rated voltage 12 VDC (neg. earth)
Max output 4 x 40 W
Speaker impedance 4 ohm/channel
Dimensions 184 x 106 x 181 mm
Weight 1.35 kg
FM receiver
Frequency range 522-1620 kHz
Signal/noise ratio 50 dB
Sensitivity 10 dB
AM receiver
Frequency range 522-1620 kHz
Intermediate frequency 455 MHz ± 5%
Signal/noise ratio 45 dB
Sensitivity 40 dB
USB/SD card
Frequency range 20 Hz-20 kHz
Signal/noise ratio >50 dB
T.H.D <10% (1kHz)
DESCRIPTION
Car stereo
IR
Receiver for signals from remote
control.
MIC
Microphone, when Bluetooth is
set to phone mode.
MOD
Changes function mode. Used to
switch between AUX, SD card etc.
SAFETY INSTRUCTIONS
• Read the operating instructions
carefully for the electrical connec-
tions. The car stereo will be dam-
aged if it is not connected properly.
• The car stereo should if possible be
installed by a professional.
• Do not connect the power cable
before all the other connections to
the car stereo have been completed.
• Insulate all exposed cables to avoid
short circuiting.
• All loose cables should be fastened
on completion of the installation.
• The car stereo is intended to run on
a 12–15 V system with negative
earth. Check that the car has such
an electrical system.
• Connect the car stereo according to
the wiring diagram, otherwise it
will not work as intended and can
be damaged.
• The speakers must be connected
correctly, otherwise there is a risk of
damaging both the amplier and
the speakers.
• If the antenna cable (BLUE) is
earthed or connected wrong the
car stereo can be damaged or
impossible to start.
• If the power cable (YELLOW) is
earthed or connected wrong the
car stereo can be damaged or
impossible to start or switch o.
