ASSEMBLY INSTRUCTIONS
NOTE: Always lock all 4 castors before entering the scaffold!
The castors are locked by pressing the brake down.
PACK 1 PACK 2
7.1 Mounting the guardrail
7.1.1 Mount the guardrail frames on both sides of the scaffold. Remember to
secure the frame by pushing the clip through the hole in the frame until the clip is
locked.
7.1.2 Mount two double guardrails. Remember to mount the guardrail from the
inside onto the vertical tubes. Be aware that the claws locks correctly.
7.1.3 Now the plat-
form can be moved
to the top rung on
the base modul (rung
6 from below). Re-
member to secure
the platform with the
storm locks!
7. BASE MODULE WITH RAILING
Follow the instructions from point 6. BASE MODUL, until 6.2.2 and
then continue with the following. If the platform is located on the top
rung, it may be advantageous to move it a few rungs down and mount
from there.
