Instruction manual
70 11/2019
Note: extreme length of unfolding exhaust pipe is 1500mm, please
shorten the length as much as possible and keep it level as much as
possible when installing.
3. Free access of exhaust pipe is important, installation errors will bring
bad influence of machine.
4. Avoid exhaust-pipe with sharp bend.
5. Make sure air in exhaust pipe can run smoothly.
OPERATION
Control panel:
⑦ ⑥ ③ ④ ⑤ ④ ③ ② ①
Remote control:
③
⑤ ②
⑧ ⑦
③ ①
Note: Remote control operation function is same as the control panel on
unit. Install 2 pieces of LR03 1.5V AAA batteries (not included) into the
remote control.
1 Power
2 Mode
3 Temperature/ Time adjusting
4 Indicator light
5 LED display
6 Fan speed
7 Timer
8 Sleep
