ASSEMBLY INSTRUCTIONS
Step 1
Step 2
Put the flame tamer (D) into the firebox (A).
D
AA x4
BB x4
Secure the fire box to the leg stand using the 4 M6 x 12 screws (AA) and washers
(BB). Insert a washer and screw into the 4 holes from the inside of the fire bowl,
and use a phillips head screw driver to secure. Do not over-tighten as this may
cause damage to the surface of the fire bowl.
To Next Page
