A
4pcs
H
2 pcs
B
4 pcs
I
2 pcs
C
2 pcs
J
Bolt
M6 x 35 mm
4 pcs
D
2 pcs
K
2 pcs
E
12pcs
L
4 pcs
F
4 pcs
M
2 pcs
G
2 pcs
Bolt
M5 x 32 mm
Bolt
M6 x 15 mm
Flat Washer
Ø4.0 mm
Lock Washer
Ø5.0 mm
Flat Washer
Ø6.0 mm
Nut M6
Bolt
M5 x 10 mm
Wing Nut
Nut M5
Bolt
M4x 20 mm
Nut M4
Nut M8
