ASSEMBLY INSTRUCTIONS
NOTE: Once the wheel cover is
secure, it cannot be removed.
Be sure to test that the wheels
move smoothly before securing
with the wheel cover.
Step 5
Insert the wheel axel (H) into the hole at the end of the right leg sections (I), near
the cylinder mounting base (E). Attach a wheel (G) to either side of the axle. Ensure
wheels are secured correctly and are moving smoothly before securing with a wheel
cover (F). Use a hammer and gently tap the wheel covers to lock the wheels in place.
Step 6
Assemble right leg frame (I) to the upper panel (B), and lock by 2pcs short bolt (BB)
and 2pcs R pin (EE). Ensure upper panel is facing flat side down and leg frame is
positioned with the wheels and cylinder mounting base facing up.
H
F
G
x2
I
E
x2
B
EE x2
BB x2
To Next Page
