STEP 1 : ASSEMBLING THE FRAME
You will need the following parts to complete
section 1:
2 x Top tube with A marking
2 x Top tube with B marking
2 x Top tube with C marking
2 x Top tube with D marking
8 x L legs
4 x V legs
- Part A
- Part B
- Part C
- Part D
2 x Top tube with E marking
- Part E
2 x Top tube with F marking
- Part F
- Part G
- Part H
16 x Self tapping screws and washers
- Part Q
You will also need a cross-head screwdriver (not
supplied).
y
Fisrt
ou will need to assemble the leg bases
of your OvalPOD. This will require 2 x L-legs
and 1 x V Leg.
Note: Do not screw the sections together yet.
Lay out the 2 x L-legs and 1 x Centre Leg so that it
makes a ‘W’ shape. Join the three pieces so the
screw holes line up.
Repeat this step with the remaining pieces to
make 4 x ‘W Legs’. Leave to one side when
finished.
Layout Top Rail B, Top Rail A and Top
Rail C curving away from you as if
you are making the trampoline
upside down and a
ach. You should
only
be able to see 2 spring holes
on each top rail.
A
A
B
B
C
Layout Toprail D, E and F cu rving
away from you and ensuring you can
top rail. Connect Top rail D together
sleeve on top rail D is on the left
side. Attach this to the other top rails.
D
D
E
E
F
Assemble 1 (A, B, C)
Assemble 1 (D, E, F )
only see 2 spring holes on each
A
B
C
D
E
F
H
Self tapping screw and washer
Cross-head screwdriver
G
