23
Motor size Motor OF311 Motor OF312
Voltage Volt 120 230 230 120 230 230
Frequency Hz 60 50 60 60 50 60
Power HP 0,33 0,33 0,33 0,60 0,60 0,60
kW 0,24 0,24 0,24 0,44 0,44 0,44
Displacement l/min 84 67 84 168 134 168
CFM 2,97 2,37 2,97 5,93 4,73 5,93
FAD @ 8 Bar ***
l/min 34 26 34 64 58 64
CFM 1,20 0,92 1,20 2,26 2,05 2,26
Max. pressure**
Bar 6 6 6 6 6 6
PSI 90 90 90 90 90 90
Max. current
Amps 4,7 2,6 2,7 8,0 3,4 3,8
Weight Kg 10 10 10 13 13 13
Lbs 22 22 22 29 29 29
Dimensions (l x w x h)
mm 230 x 140 x 240 320 x 140 x 240
Inch 9.0 x 5.5 x 9.5 12.5 x 5.5 x 9.5
Model OF301 - 4B OF302 - 4B OF302 - 15B
Tank size liter 4 4 15
US gallon
1,1 1,1 4,0
Weight kg 19 22 25
lbs 42 49 55
Dimensions (l x w x h)
mm 390 x 310 x 350 390 x 320 x 350 380 x 380 x 530
Inch 15,5 x 12,5 x 13,5 15,5 x 12,5 x 13,5 15,0 x 15,0 x 21,0
Pumping time
(0-8 bar/0-120 psi)
@ 50 Hz sec. 90 45 165
@ 60 Hz
sec. 75 40 135
Noise level @ 1 m @ 50 Hz
dB(a) 65 65 65
@ 60 Hz
dB(a) 66 66 66
Model OF302 - 25B OF302 - 25BD2** 2*OF302 - 40B 2*OF302-40BD2**
Tank size liter 25 25 40 40
US gallon
6,6 6,6 10,6 10,6
Weight kg 28 33 46 59
lbs 62 73 101 130
Dimensions (l x w x h)
mm 380 x 380 x 610 510 x 460 x 610 560 x 450 x 610 560 x 540 x 630
Inch 15,0 x 15,0 x 24,0 20,0 x 18,0 x 24,0 22,0 x 18,0 x 24,0 22,0 x 21,0 x 25,0
Pumping time
(0-8 bar/0-120 psi)
@ 50 Hz sec. 270 325 220 260
@ 60 Hz
sec. 225 250 180 220
Noise level @ 1 m @ 50 Hz
dB(a) 65 65 68 68
@ 60 Hz
dB(a) 66 66 69 69
**
Displacement is reduced by approx. 18-20% on units with dryer (D). Min. pressure required to operate dryer: 6 bar
Technical modifications reserved.
The figures in the tables are based on the unit working in fairly clean air, at ambient temperatures around 20-40°C, relative humidity
near 50% and operating at sea level. The performance of the product will be adversely effected at high altitudes. For further information
on the wirings isolations class: See data table on the motor.
Technical data
