Lit push-buttons must have a separate N terminal.
￭ Fit the switch insert in the appliance box, the connection terminals must be at
the bottom.
Do not attach or replace the cover under voltage, otherwise this might cause a
malfunction.
￭ Attach the frame and the cover.
￭ Switch on mains voltage.
The load can be switched by briefly pressing the
TEST
button (1).
Setting the time function
￭ Press the
TEST
button (1) for longer than 4 seconds.
LED lights up in the colour of the set run-on time, see table.
￭ Release the
TEST
button (1) briefly and then press it repeatedly until the LED
lights up in the colour of the desired time.
The set time is automatically saved after 30 seconds or after pressing the
TEST
button (1) for approx. 4 seconds. When the LED goes out, the saving
process was successful.
LED colour Set time
green Function off
white 1 minute
blue 5 minutes
yellow 30 minutes
red 60 minutes
Connecting and mounting the device as a room thermostat (see figure 3)
Recommended installation height: 1.50 m.
