Smart Radio DAB+ and Smart Radio DAB+ Bluetooth
31.07.20207 / 70024075202
7 Commissioning
The radio scans and saves all receivable channels for DAB+ and FM. The 8 strongest channels are saved as
favourite.
The time is applied automatically during reception of favourite 1. The time can also be set via the menu.
8 Technical data
Rated voltage AC 230 V ~
Mains frequency 50/60 Hz
Connection Screw terminals
Cable cross-section 1 x 2.5 mm² or 1 x 1.5 mm²
Power draw
Standby < 1 W
Operation < 4 W
Temperature range 0 ... 50 °C
Humidity 15 ... 90 % (no dew)
DAB frequency range 174 ... 240 MHz
VHF frequency range 87.5 ... 108 MHz
Bluetooth
Frequency range 2.402 ... 2.48 GHz
Transmission power Class 2 < 4 dBm
Transmitter range type 10 m
Protection rating IP20
Connecting cable loudspeaker
Twin cable H03VH-H, 2x0.75
Alternative JY-(St)- Y 2x2x0.6
Length max. 5 m
Loudspeaker LSM…
Rated load capacity 2.5 W
Impedance 4 Ω
Frequency range 120 ... 15000 Hz (-10 dB)
9 Accessories
Cable aerial Art.-No.: RAD-ANT
10 Warranty
Warranty is oered according to the statutory provisions via specialist dealers.
