4.10.5 Transporting two palletised loads above each other
Z
ERC 212z-216z only
Z
For double decker option only
CAUTION!
Risk to operational stability
In order not to jeopardize the operational stability, pay attention to the weight when
transporting two pallets so that the truck does not tip over.
u
In order not to jeopardize the operational stability, the heavier pallet should always
be transported underneath.
Requirements
– Load raised correctly.
– Load handler lowered as far as possible but without touching the lower load.
– Good ground conditions.
Procedure
• Accelerate and decelerate with care.
• Adapt your travel speed to the conditions of the route and the load you are
transporting.
• Travel at a constant speed.
• Watch out for other traffic at crossings and passageways.
• Always travel with a lookout at blind spots.
• On slopes and inclines always carry the load facing uphill, never approach at an
angle or turn.
103
04.19 en-GB
