Jungheinrich TFG 680 User Manual

23
11.14 EN
3.2 Dimensions
DFG 660-690
*) The data listed in the table corresponds to the standard version.
Model 660 670 680 690
a/2 Safety distance 100 100 100 100 mm
h
1
Collapsed height* 2710 2710 3010 3160 mm
h
3
Lift* 3600 3600 3600 3600 mm
h
4
Extended height* 4510 4510 4810 4960 mm
h
6
Overhead guard
height*
2705 2705 2705 2705 mm
h
7
Seat height* 1600 1600 1600 1600 mm
h
10
Coupling height 500 500 500 500 mm
Į
Mast tilt, fwd.* 6 6 6 6 °
ȕ
Mast tilt, back* 9 9 9 9 °
l
1
Length, including
forks*
4760 4770 4880 5035 mm
l
2
Length, including fork
shank*
3560 3570 3680 3835 mm
b
1
Overall width* 1820 2002 2002 2100 mm
s/e/l Fork dimensions* 60/150/
1200
60/150/
1200
70/150/
1200
70/150/
1200
mm
m
1
Ground clearance,
laden, below mast*
230 230 230 230 mm
m
2
Ground clearance
centre wheelbase*
250 250 250 250 mm
Fork carriage ISO
2328 class / type A, B
4 A4 A4 A4 Amm
b
3
Fork carriage width 1800 1800 2000 2100 mm
Ast Working aisle width for
pallets 800 x 1200
lengthways
5320 5330 5440 5745 mm
Ast Working aisle width for
pallets 1000 x 1200
traverse
5120 5130 5240 5545 mm
Wa Turning radius 3250 3250 3350 3650 mm
b
13
Smallest turning
radius
1270 1270 1320 1390 mm
x Load distance* 680 680 700 700 mm
c Load centre of gravity 600 600 600 600 mm
y Wheelbase 2295 2295 2395 2545 mm
