32 Mesa Barcode Scanner Owner’s Manual
Mesa Barcode Scanner Specications
Imager and Decoder Motorola/Symbol SE4500
imager and PL4507
624MHz decoder
Sensor Resolution 752 X 480
Field of View Horizontal 40°, vertical
25°
Reading Angles Skew & pitch ±60°, roll
360°
Read Range 1” – 24” depending on
code type, size, and
density
Symbologies All common 1D, 2D
(PDF417, MicroPDF417,
Composite, RSS, TLC-39,
Data matrix, QR code,
Micro QR code, Aztec,
MaxiCode, Postal codes)
Trigger Buttons Programmable
Aiming Crosshair Pattern Visible with low light
illumination
Barcode Connector™
Utility
Wedge and
conguration
Operating Temperature -22°F to 131°F / -30°C to
55°C
