Figure 18: Inserting the AIr Filter into a PTX10008 Front Panel
g100732
1
1—Air filter
4. Move the air filter frame over the front panel and turn the knob on the air filter frame clockwise back in place.
NOTE: You must replace the filter every 6 months.
Step 6–Connect Power to the Chassis
IN THIS SECTION
Ground the PTX10008 | 20
Install AC Power Supplies (JNP10K-PWR-AC) | 21
Install AC/HVAC/HVDC Power Supplies (JNP10K-PWR-AC2) | 25
Install DC Power Supplies (JNP10K-PWR-DC) | 29
Install Dual DC Power Supplies (JNP10K-PWR-DC2) | 35
19
