INSTALLATION INSTRUCTIONS
Juno Smart LED RGBW Speaker LED Trim Kit
912-00386-001 REV F
DATE 10/2023
PAGE | 6
Step 4: SET UP EACH INSTALLED FIXTURE FOR SMART LIGHTING CONNECTIVITY
4.1 Ensure each unit installed is connected properly. Then, connect power back to
fixtures by returning the circuit breaker to ON or by setting the appropriate fuse at the
fuse box.
4.2 When power is first returned to the fixture, the light output will be set to max
brightness at 3000K. (Figure 4)
4.3 Decide if Speaker Light will be used with SmartThings, Google Home, or Amazon Alexa. If D2D is not
used for primary control, the fixture must be connected to a Zigbee enabled hub.
A. SmartThings Direct to Phone (D2D)
i. Using an iOS or Android phone, add Speaker Light with SmartThings app (made by
Samsung Electronics Co., Ltd.).
Note: A Samsung SmartThings account must be created within the app to continue with the smart fixture set-up process.
ii. Click “+” then “Scan for New Devices”, as seen in Figure 5. Follow the prompts to
connect each fixture. If fixture is not shown in app, try restarting the app and turning the
light on and off at the switch.
Note: Allows for lighting controls without the use of a hub. On\off, dim, CCT, RGB functionalities are available to user.
One Lithonia Way · Conyers, GA 30012 · Phone 1-(800)705-7378
Visit us at www.acuitybrands.com/juno-recessed
© 2023 Acuity Brands Lighting, Inc.
