JVA Z Series Installer Manual

6
JVA ELECTRIC FENCE SYSTEMS JVA ELECTRIC FENCE SYSTEMS
Specications
3.3 Z14/Z14RSpecicationTable
SpecicationName
Specication
Energizer Output Voltage 9.0kV peak no load
Peak Output Energy 4 Joules at 500 Ohm, Limited to 2.5J in Group Mode
Pulse Rate Locked at 0.9 Hz
12V DC Power Consumption
Energizer On – 550mA average, 700mA peak.
EnergizerO󰀨–28mA
Not including keypad or Auxiliary power
AC Power Input
16-18Vac 1A
2
Battery Charger Output
Float voltage 14V, 700mA, short circuit protection, reverse
battery protection
Switched Outputs Three30V1A“FormC”change-overcontacts(Z14Ronly)
Two 12V 2.5A maximum combined load powered Outputs
Recommended Operating
Temperature
-15°C to +50°C
Enclosure
IP4x ABS Plastic
Size 300mm high, 190mm wide, 115mm deep
Weight – packed no battery 1.9 kg
3.4 Z18SpecicationTable
SpecicationName
Specication
Energizer Output Voltage 8.5kV peak no load
Peak Output Energy 8 Joules
Pulse Rate Locked at 0.9 Hz
12V DC Power Consumption Energizer On – 870mA average, 1220mA peak.
EnergizerO󰀨–28mA
Not including keypad or Auxiliary power
AC Power Input
16-18Vac 1.5A2
2
Battery Charger Output Float voltage 14V, 700mA, short circuit protection, reverse
battery protection
Switched Outputs Three30V1A“FormC”change-overcontacts
Three 12V 2.5A maximum combined load powered output
Recommended Operating
Temperature
-15°C to +50°C
Enclosure IP4x ABS Plastic
Size 300mm high, 190mm wide, 115mm deep
Weight – packed no battery 2.5 kg
2
A 24Vdc 1.5A supply can be used in place of the 16Vac. The correct connection is +24V to the right AC pin,
GND to the left AC pin. Due to the stored energy in a 24Vdc plug-pack, an AC Fail could occur 5 minutes
before the Energizer reports this fault
