JVA Z Series Installer Manual

38
JVA ELECTRIC FENCE SYSTEMS JVA ELECTRIC FENCE SYSTEMS
Appendices
APPENDIXA:GroupSimultaneous
Pulse Feature
GroupSimultaneousPulseFeature
In some Industrial Installations it may be preferable to provide the ability to link multiple
Energizers into a group. When linked the individual Z-Series Energizers become a
“Group”. Members of a group have simultaneous high voltage output pulses and
act as is they are one energizer with multiple outputs. This is designed so that no
possible combination of individual outputs can be dangerous.
5
GroupModeProgramming(26x#)
A group MUST have only 1 master. The other Energizers in the group are slaves.
For the Z14R Energizers, if there is no
Master, a Slave will display Error 4 on
the Status LED when Armed and it will
not electrify the fence.
For every other Z-Series Energizer,
if there is no Master, each Slave will
electrify the fence (pulse) when Armed.
However, the simultaneous pulse feature
will NOT be operating.
Note1: Do not interconnect the
energizers via the keypad
bus until after they are
programmed.
Note2: If more than one keypad is
used,theywillneeddi󰀨erent
addresses (see page 23:
7.3 Changing the Keypad
Messages and Address).
Note3: If Perimeter Patrol is used any
keypad in the system should
not have address 2. (See Page
19, Program this Keypad.)
Value (x) Mode
0 No Group
1 Master
2 Slave 1
3 Slave 2
4 Slave 3
5 Slave 4
6 Slave 5
7 Slave 6
8 Slave 7
9 Slave 8
10 Slave 9
11 Slave 10
12 Slave 11
13 Slave 12
14 Slave 13
15 Slave 14
5
Patent Applied For.
