Page 3

Label Type Descripon

16Vac 3 Way 16Vac 1.5A power input plus earth. Connecon of

the earth is only required where local safety or wir-

ing codes demand it. This should be connected to the

cabinet or mains earth NOT the fence earth.

Ba Battery

leads

12V dc or baery connecon via F1

(4 Amp slow blow fuse).

Relay 3 3 Way “Form C” relay with dry contacts. Default operaon

Fence Alarm

Relay 4 3 Way “Form C” relay with dry contacts. Default operaon

Zone Armed

Relay 5 3 Way “Form C” relay with dry contacts. Default operaon

General Alarm

1.3 JUMPERS

Jumpers allow you to turn on and o dierent features, or reset the device

to defaults.

JUMPER FUNCTION

J3 Inhibit AC fail error.

J3(Z14R) Tamper disable.

J4 Factory default jumper - on for normal operaon.

O to return programmable opons to factory defaults on

power up.

J8 Disable on board beeper

J5, J6 & J7 Supplies +12V to the Common terminal of Relay 3, 4, 5.

Jumpers located on the top right hand side of the board
