14
INPUT 2 INPUT 1
S-VIDEO
VIDEO
R -
AUDIO -
L
S-VIDEO
VIDEO
R -
AUDIO -
L
DIGITAL-IN
75Ω
(UH
F/VHF)
Coaxial Cable
Cable or Antenna
Output
OR
VCR
IN
OUT
Two-Way
Splitter
IN
OUT
V L R
Cable Box
OUT IN
IN
OUT OUT
TV Rear Panel
TV Rear Panel
Quick Setup Connections
Notes:
• If your VCR is a mono sound unit, it will have only one audio out jack. Connect it to the
LEFT AUDIO INPUT on the rear of the TV.
• Use the S-Video connection if possible for superior picture quality.
• Your VCR must be turned on to view premium cable channels.
Diagram #2
Note:
• If you do not have a cable box, connect the cable wire from the wall outlet into the back of
the TV.
75Ω
(UHF/VHF)
Coaxial Cable
Cable or Antenna
Output
Cable Box
IN OUT
OR
TV Rear Panel
Diagram #1
LCT1827-001B-A ENG 14 7/25/05, 9:13:18 AM
