EN-7

Power requirement : AC 110 V to 240 V`,

50/60 Hz

Power consumption : 23 W

Output

Charge : DC 8.5 V , 1.3 A

VTR : DC 6.3 V , 1.8 A

Charging system : Constant current,

peak detection,

timer controlled

Dimensions : 140 (W) x 42 (H) x

68 (D) mm

Weight : Approx. 300 g

SPECIFICATION

Use the AC Power Adapter (connect as shown in the

illustration above).

NOTE:

The supplied AC Power Adapter/Charger features

automatic voltage selection in the AC range from

110 V to 240 V.

USING AC POWER

Core Filter

DC cord

DC OUT

terminal

AC Power Adapter/

Charger AA-V15EG

To AC outlet
