JVC AV-14A3 User Manual

No. 52029
A
V-14A3
43
!
Symbol No. Part No. Part Name Description
CAPACITOR
C1924 QETN1HM-475Z E CAP. 4.7
µ
F 50V M
C1925 QETN1VM-476Z E CAP. 47µF 35V M
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
!
C1929 QFKA2JK-103 MM CAP. 0.01
µ
F 630V K
!
C1931 QCZ0364-681 C CAP. 680pF 2kV K
C1932 NDC31HJ-221X C CAP. 220pF 50V J
C1941 QCZ0364-561 C CAP. 560pF 2kV K
C1942 QEZ0203-107 E CAP. 100µF 160V M
C1944 QCB32HK-222Z C CAP. 2200pF 500V K
C1945 QEHR1EM-108Z E CAP. 1000µF 25V M
C1946 QETN1EM-108Z E CAP. 1000µF 25V M
C1947 QCB32HK-222Z C CAP. 2200pF 500V K
C1948 QETN1EM-108Z E CAP. 1000
µ
F 25V M
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1976 QETN1EM-227Z E CAP. 220µF 25V M
C1977 QETN1CM-227Z E CAP. 220
µ
F 16V M
C1978 QETN1EM-227Z E CAP. 220
µ
F 25V M
C1979 QETN1AM-227Z E CAP. 220µF 10V M
!
C1991 QCZ9079-102 C CAP. 1000pFAC250V M
!
C1992 QCZ9079-102 C CAP. 1000pFAC250V M
! C1993 QCZ9079-152 C CAP. 1500pFAC250V M
TRANSFORMER
T1501 CE40203-00CJ1 DRIVE TRANSF.
! T1522 QQH0108-001 F.B.TRANSF.
! T1921 QQS0161-001 SW TRANSF.
COIL
L1001 QQL244K-8R2Z COIL 8.2
µ
H K
L1101 QQL244J-2R2Z COIL 2.2µH J
L1103 QQL244K-8R2Z COIL 8.2µH K
L1551 QQLZ034-140 HEATER CHOKE
L1701 QQL244J-5R6Z COIL 5.6µH J
L1941 QQL26AK-820Z COIL 82µH K
L1942 QQL244J-4R7Z INDUCTOR
L1943 QQL244J-4R7Z INDUCTOR
DIODE
D1001 MTZJ33A-T2 ZENER DIODE
D1301 MTZJ9.1B-T2 ZENER DIODE
D1302 MTZJ9.1B-T2 ZENER DIODE
D1305 AK04-T2 SB DIODE
D1306 QRE121J-121Y C R 120
Ω
1/2W J
D1341 MA111-X SI.DIODE
D1421 MTZJ75-T2 ZENER DIODE
D1423 1SR124-400A-T2 SI.DIODE
D1425 MA111-X SI.DIODE
D1427 MTZJ27B-T2 ZENER DIODE
D1501 MTZJ6.8C-T2 ZENER DIODE
D1551 RGP10J-5025-T3 SI.DIODE
D1552 RGP10J-5025-T3 SI.DIODE
D1553 MTZJ9.1B-T2 ZENER DIODE
D1554 MA111-X SI.DIODE
D1557 1SR124-400A-T2 SI.DIODE
D1571 MTZJ7.5S-T2 ZENER DIODE
D1581 MTZJ20B-T2 ZENER DIODE
D1582 RGP10J-5025-T3 SI.DIODE
D1651 MA111-X SI.DIODE
D1652 MTZJ12C-T2 ZENER DIODE
D1653 MA111-X SI.DIODE
D1654 MTZJ12C-T2 ZENER DIODE
D1655 MA111-X SI.DIODE
D1656 MA111-X SI.DIODE
D1657 MA111-X SI.DIODE
D1703 SPR-39MVWF LED
D1707 MA111-X SI.DIODE
D1731 MA111-X SI.DIODE
!
D1901 G2SBA60 BRIDGE DIODE
D1921 RGP10J-5025-T3 SI.DIODE
D1925 RGP10J-5025-T3 SI.DIODE
D1927 MTZJ36A-T2 ZENER DIODE
D1928 MTZJ3.3A-T2 ZENER DIODE
D1929 MTZJ5.6A-T2 ZENER DIODE
D1930 RGP10M-5010-T3 SI.DIODE
D1931 MA111-X SI.DIODE
D1933 MTZJ16C-T2 ZENER DIODE
!
Symbol No. Part No. Part Name Description
DIODE
D1941 RU3AM-LFC4 SI.DIODE
D1942 RU3YX-LFC4 SI.DIODE
D1943 RGP10J-5025-T3 SI.DIODE
D1982 MA111-X SI.DIODE
D1983 MA111-X SI.DIODE
TRANSISTOR
Q1102 2SC5083/L-P/-T SI.TRANSISTOR
Q1301 2SB709A/QR/-X SI.TRANSISTOR
Q1302 2SD601A/QR/-X SI.TRANSISTOR
Q1351 STC344-T SI.TRANSISTOR
Q1352 STC344-T SI.TRANSISTOR
Q1353 STC344-T SI.TRANSISTOR
Q1401 DTC124ESA-T DIGI.TRANSISTOR
Q1402 2SD601A/QR/-X SI.TRANSISTOR
Q1521 2SC2655/Y/-T SI.TRANSISTOR
!
Q1522 2SD2658LS-YB11 POWER TRANSISTOR H.OUT
Q1571 2SA1208/ST/Z1-T SI.TRANSISTOR
Q1572 2SD601A/QR/-X SI.TRANSISTOR
Q1651 2SD601A/QR/-X SI.TRANSISTOR
Q1652 2SD601A/QR/-X SI.TRANSISTOR
Q1653 2SB709A/QR/-X SI.TRANSISTOR
Q1702 2SD601A/QR/-X SI.TRANSISTOR
Q1703 UN2212-X DIGI.TRANSISTOR
Q1708 UN2212-X DIGI.TRANSISTOR
Q1710 UN2212-X DIGI.TRANSISTOR
Q1803 2SC1815/YG/-T SI.TRANSISTOR
Q1804 2SD601A/QR/-X SI.TRANSISTOR
Q1974 2SA966/OY/-T SI.TRANSISTOR
Q1975 UN2212-X DIGI.TRANSISTOR
IC
IC1301 NN5198K I C
IC1421 AN5522 I C
IC1651 AN5265 I C
! IC1701 MN1873287JL1 I C
IC1702 AT24C08-21DMG3 I C (SERVICE)
IC1703 L78LR05E-MA I C
IC1704 PIC-47143SY IR DETECT UNIT
! IC1921 STR-W5753A/F5 I C
IC1971 BA17809T I C
IC1972 BA17805T I C
OTHERS
LC30349-001A-H LED HOLDER
! CP1981 ICP-N25-Y I.C.PROTECT
!
CP1982 ICP-N75-Y I.C.PROTECT
!
F1901 QMF51E2-3R15J4 FUSE 3.15A
FC1901 CEMG002-001Z FUSE CLIP
FR1557 QRJ146J-2R2X C R 2.2
Ω
1/4W J
J1002 QNN0384-001 PIN JACK
J1003 QNN0281-003 PIN JACK or CEMN065-001
J1004 QNN0281-002 PIN JACK or CEMN065-002
!
J1005 QNS0197-001 3.5 JACK
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR1113-001Z FERRITE BEADS
K1901 QQR1113-001Z FERRITE BEADS
K1902 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR11 13-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS
! LF1901 QQR0673-002 LINE FILTER
S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL-
S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH-
S1705 QSW0619-003Z TACT SWITCH MENU
! S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
!
SK1351 CE42554-001 C R T SOCKET or QNZ0536-001
!
TH1901 QAD0121-9R0 THERMISTOR or QAD0119-9R0
! TU1001 QAU0246-002 TUNER
! VA1901 ERZV10V621CS VARISTOR or QAF0052-621
!
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 C RESONATOR
[ AV-14A3
/AU
]
