Symbol No. Part No. Part Name Description
OTHERS
! LF1901 QQR0527-002 LINE FILTER
PC1701 P1241-04 C D S
S1701 QSW0619-003Z PUSH SWITCH VOL+
S1702 QSW0619-003Z PUSH SWITCH VOL-
S1703 QSW0619-003Z PUSH SWITCH CH+
S1704 QSW0619-003Z PUSH SWITCH CH-
S1705 QSW0619-003Z PUSH SWITCH MENU
!
S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
! SK1351 QNZ0537-001 CRT SOCKET or QNZ0536-001
! TH1901 QAD0121-9R0 P THERMISTOR or QAD0119-9R0
TU1001 QAU0282-001 TUNER
!
VA1901 ERZV10V621CS Z N R or QAF0052-621
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 CER RESONATOR
