JVC AV-21DMT3 - Page 43

No. 52023
A
V-2135EE
52
!
Symbol No. Part No. Part Name Description
CAPACITOR
C1719 QETN1HM-105Z E CAP. 1
µ
F 50V M
C1720 NCB31HK-103X C CAP. 0.01µF 50V K
C1721 NCB31EK-333X C CAP. 0.033 µF 25V K
C1722 NDC31HJ-101X C CAP. 100pF 50V J
C1724 NDC31HJ-560X C CAP. 56pF 50V J
C1728 NDC31HJ-181X C CAP. 180pF 50V J
C1729 NDC31HJ-181X C CAP. 180pF 50V J
C1730 NCB31HK-103X C CAP. 0.01µF 50V K
C1741 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1742 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1743 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1744 NCB31HK-103X C CAP. 0.01µF 50V K
C1805 QETN1CM-227Z E CAP. 220µF 16V M
C1806 QETN1CM-477Z E CAP. 470µF 16V M
C1811 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1841 NCB31HK-152X C CAP. 1500pF 50V K
! C1901 QFZ9078-224 M P F CAP 0.22µF AC275V M
! C1904 QCZ9015-102 C CAP. 1000pFAC250V Z
! C1905 QCZ9015-102 C CAP. 1000pFAC250V Z
!
C1907 QCZ9015-102 C CAP. 1000pFAC250V Z
C1909 QEZ0552-127 E CAP. 120µF 400V M
! C1910 QFZ9078-473 M P F CAP 0.047µF AC275V M
C1922 QFLC1HJ-104Z M CAP. 0.1µF 50V J
C1924 QETN1HM-475Z E CAP. 4.7µF 50V M
C1925 QETN1VM-476Z E CAP 47µF 50V M
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
C1929 QFKA2JK-103 M M CAP 0.01pF 630V K
C1931 QCZ0364-681 C CAP 680pF 2KV K
C1932 NDC31HJ-681X C CAP. 680pF 50V J
C1941 QCZ0364-561 C CAP 560pF 2KV K
C1942 QEZ0203-107 E CAP. 100µF 160V M
C1944 QCB32HK-222Z C CAP. 2200pF 500V K
C1945 QEHR1EM-108Z E CAP. 1000µF 25V M
C1946 QETN1EM-108Z E CAP. 1000µF 25V M
C1947 QCB32HK-222Z C CAP. 2200pF 500V K
C1948 QETN1EM-108Z E CAP. 1000µF 25V M
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1961 QETN1HM-475Z E CAP. 4.7µF 50V M
C1976 QETN1EM-227Z E CAP. 220µF 25V M
C1977 QETN1CM-227Z E CAP. 220µF 16V M
C1978 QETN1EM-227Z E CAP. 220µF 25V M
C1979 QETN1AM-227Z E CAP. 220µF 10V M
!
C1991 QCZ9079-102 C CAP. 1000pFAC250V M
! C1992 QCZ9079-102 C CAP. 1000p FAC250V M
! C1993 QCZ9079-222 C CAP. 2200pFAC250V M
TRANSF
T1501 QQR1244-001 DRIVE TRANSF.
! T1522 QQH0131-001 F B T
!
T1921 QQS0161-001 SW TRANSF.
COIL
L1001 QQL244K-8R2Z COIL 8.2µH K
L1101 QQL244J-2R2Z COIL 2.2µH J
L1103 QQL244K-8R2Z COIL 8.2
µ
H K
L1551 QQLZ034-670 HEATER CHOKE
L1701 QQL244J-5R6Z COIL 5.6µH J
L1941 QQL26AK-820Z COIL 82
µ
H K
L1942 QQL244J-4R7Z PEAKING COIL
L1943 QQL244J-4R7Z PEAKING COIL
DIODE
D1001 MTZJ33A-T2 ZENER DIODE
D1301 MTZJ9.1B-T2 ZENER DIODE
D1302 MTZJ9.1B-T2 ZENER DIODE
D1305 AK04-T2 DIODE
D1306 QRE121J-121Y C R 120Ω 1/2W J
D1341 MA111-X CHIP DIODE
D1421 MTZJ75-T2 ZENER DIODE
D1423 1SR124-400A-T2 SI DIODE
!
Symbo l No. Part No. Part Name Description
DIODE
D1425 MA111-X CHIP DIODE
D1427 MTZJ27B-T2 ZENER DIODE
D1501 MTZJ6.8C-T2 ZENER DIODE
D1551 RGP10J-5025-T3 SI DIODE
D1552 RGP10J-5025-T3 SI DIODE
D1553 MTZJ9.1B-T2 ZENER DIODE
D1554 MA111-X CHIP DIODE
D1557 1SR124-400A-T2 SI DIODE
D1571 MTZJ7.5S-T2 ZENER DIODE
D1581 MTZJ20B-T2 ZENER DIODE
D1582 RGP10J-5025-T3 SI DIODE
D1651 MA111-X CHIP DIODE
D1652 MTZJ12C-T2 ZENER DIODE
D1653 MA111-X CHIP DIODE
D1654 MTZJ12C-T2 ZENER DIODE
D1655 MA111-X CHIP DIODE
D1656 MA111-X CHIP DIODE
D1657 MA111-X CHIP DIODE
D1701 MA111-X CHIP DIODE
D1704 SLR-342VR-T16 L E D(RED)
D1705 SLR-342DU-T16 L E D (ORG)
D1707 MA111-X CHIP DIODE
D1731 MA111-X CHIP DIODE
!
D1901 G2SBA60 BRIDGE DIODE
D1921 RGP10J-5025-T3 SI DIODE
D1925 RGP10J-5025-T3 SI DIODE
D1927 MTZJ36A-T2 ZENER DIODE
D1928 MTZJ3.3A-T2 ZENER DIODE
D1929 MTZJ3.3A-T2 ZENER DIODE
D1930 RGP10M-5010-T3 SI DIODE
D1931 MA111-X CHIP DIODE
D1933 MTZJ16C-T2 ZENER DIODE
D1941 RU3AM-LFC4 SI DIODE
D1942 RU3YX-LFC4 SI DIODE
D1943 RGP10J-5025-T3 SI DIODE
D1982 MA111-X CHIP DIODE
D1983 MA111-X CHIP DIODE
TRANSISTOR
Q1102 2SC5083/L-P/-T SI.TRANSISTOR
Q1301 2SB709A/QR/-X CHIP TRANSISTOR
Q1302 2SD601A/QR/-X CHIP TRANSISTOR
Q1351 STC344-T SI.TRANSISTOR
Q1352 STC344-T SI.TRANSISTOR
Q1353 STC344-T SI.TRANSISTOR
Q1401 DTC124ESA-T DIGI. TRANSISTOR
Q1402 2SD601A/QR/-X CHIP TRANSISTOR
Q1403 2SD601A/QR/-X CHIP TRANSISTOR
Q1404 2SD601A/QR/-X CHIP TRANSISTOR
Q1521 2SC2655/Y/-T SI.TRANSISTOR
! Q1522 2SD2627-YB11 POWER TRANSISTOR H.OUT
Q1571 2SA1208/ST/Z1-T SI.TRANSISTOR
Q1651 2SD601A/QR/-X CHIP TRANSISTOR
Q1652 2SD601A/QR/-X CHIP TRANSISTOR
Q1653 2SB709A/QR/-X CHIP TRANSISTOR
Q1702 2SD601A/QR/-X CHIP TRANSISTOR
Q1703 2SD601A/QR/-X CHIP TRANSISTOR
Q1708 UN2212-X DIGI. TRANSISTOR
Q1709 2SB709A/QR/-X CHIP TRANSISTOR
Q1803 2SC1815/YG/-T SI.TRANSISTOR
Q1804 2SD601A/QR/-X CHIP TRANSISTOR
Q1974 2SA966/OY/-T SI.TRANSISTOR
Q1975 UN2212-X DIGI. TRANSISTOR
IC
IC1301 NN5198K I.C.
IC1421 AN5522 I.C.
IC1651 AN5265 I.C.
IC1701 MN1873287JK1 IC
IC1702 AT24C08-10PC I.C. (SERVICE)
IC1703 L78LR05E-MA I.C.
IC1704 PIC-47143SY IR DETECT
IC1921 STR-W5753A/F5 I.C.
IC1971 BA17809T I.C.
IC1972 BA17805T I.C.
[ AV-2135EE ]
