! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
52 No. 52061
AV-29WS3
DIODE
D3132 MA3043-X ZENER DIODE
D3141 MTZJ30A-T2 ZENER DIODE
D3142 MTZJ30A-T2 ZENER DIODE
D3143 MTZJ30A-T2 ZENER DIODE
D3201 NRSA63J-0R0X MG R 0.0¸ 1/16W J
D3202 NRSA63J-0R0X MG R 0.0¸ 1/16W J
D3203 RGP10J-5025-T3 SI. DIODE
D3204 RGP10J-5025-T3 SI. DIODE
TRANSISTOR
Q3101 2SD601A/QR/-X TRANSISTOR
Q3102 2SD601A/QR/-X TRANSISTOR
Q3103 2SD601A/QR/-X TRANSISTOR
Q3104 2SD601A/QR/-X TRANSISTOR
Q3105 2SD601A/QR/-X TRANSISTOR
Q3106 2SD601A/QR/-X TRANSISTOR
Q3121 2SC1740S/QR/-T TRANSISTOR
Q3122 2SA933AS/QR/-T TRANSISTOR
Q3123 2SC4075/DE/YA11 POWER TRANSISTOR
Q3124 2SC1740S/QR/-T TRANSISTOR
Q3125 2SC4075/DE/YA11 POWER TRANSISTOR
Q3126 2SC1740S/QR/-T TRANSISTOR
Q3127 2SC4075/DE/YA11 POWER TRANSISTOR
Q3128 2SC1740S/QR/-T TRANSISTOR
Q3129 2SC3334-T TRANSISTOR
Q3130 2SA1321-T TRANSISTOR
Q3131 2SC3334-T TRANSISTOR
Q3132 2SA1321-T TRANSISTOR
Q3133 2SC3334-T TRANSISTOR
Q3134 2SA1321-T TRANSISTOR
Q3135 2SB709A/QR/-X TRANSISTOR
Q3204 2SC1740S/QR/-T TRANSISTOR
Q3205 2SC1740S/QR/-T TRANSISTOR
Q3206 2SA933AS/QR/-T TRANSISTOR
Q3209 2SA1837 POWER TRANSISTOR
Q3210 2SC4793 POWER TRANSISTOR
Q3251 2SB709A/QR/-X TRANSISTOR
Q3252 2SD601A/QR/-X TRANSISTOR
Q3253 2SB709A/QR/-X TRANSISTOR
Q3261 2SB709A/QR/-X TRANSISTOR
Q3262 2SB709A/QR/-X TRANSISTOR
Q3263 2SB709A/QR/-X TRANSISTOR
Q3264 2SD601A/QR/-X TRANSISTOR
Q3265 2SD601A/QR/-X TRANSISTOR
Q3266 2SD601A/QR/-X TRANSISTOR
OTHERS
CL3001 QZW0027-004 WIRE CLAMP
DL3261 CE41925-001 DELAY LINE
DL3262 CE41925-001 DELAY LINE
DL3263 CE41925-001 DELAY LINE
! FR3201 QRZ9021-561 F R 560¸ 1W J
K3201 CE41492-001Z CHOKE COIL
K3202 CE41492-001Z CHOKE COIL
K3203 CE41492-001Z CHOKE COIL
K3204 CE41492-001Z CHOKE COIL
K3205 QQR1113-001Z FERRITE BEADS
K3206 QQR1113-001Z FERRITE BEADS
K3207 QQR1113-001Z FERRITE BEADS
K3208 QQR1113-001Z FERRITE BEADS
! SK3001 CE42670-001 CRT SOCKET
W3034 NRSA63J-0R0X MG R 0.0¸ 1/16W J
FRONT CONTROL PW BOARD ASS’Y (SCH-8004A-H2)
RESISTOR
R8481 IM-BW BUS WIRE
R8482 NRSA63J-124X MG R 120k¸ 1/16W J
R8483 NRSA63J-683X MG R 68k¸ 1/16W J
R8484 NRSA63J-562X MG R 5.6k¸ 1/16W J
R8485 NRSA63J-562X MG R 5.6k¸ 1/16W J
R8486 NRSA63J-333X MG R 33k¸ 1/16W J
R8487 NRSA63J-332X MG R 3.3k¸ 1/16W J
R8488 NRSA63J-154X MG R 150k¸ 1/16W J
R8489 NRSA63J-104X MG R 100k¸ 1/16W J
R8491 NRSA63J-0R0X MG R 0.0¸ 1/16W J
R8492 NRSA63J-0R0X MG R 0.0¸ 1/16W J
R8495 NRSA63J-152X MG R 1.5k¸ 1/16W J
R8497 NRSA63J-562X MG R 5.6k¸ 1/16W J
R8499 QRE121J-561Y C R 560¸ 1/2W J
R8801 NRSA63J-332X MG R 3.3k¸ 1/16W J
R8802 NRSA63J-392X MG R 3.9k¸ 1/16W J
R8803 NRSA63J-682X MG R 6.8k¸ 1/16W J
R8805 NRSA63J-682X MG R 6.8k¸ 1/16W J
R8807 NRSA63J-181X MG R 180¸ 1/16W J
R8808 NRSA63J-221X MG R 220¸ 1/16W J
R8809 NRSA63J-331X MG R 330¸ 1/16W J
R8810 NRSA63J-471X MG R 470¸ 1/16W J
R8811 NRSA63J-821X MG R 820¸ 1/16W J
R8812 NRSA63J-122X MG R 1.2k¸ 1/16W J
R8813 NRSA63J-471X MG R 470¸ 1/16W J
R8815 QRE121J-271Y C R 270¸ 1/2W J
R8816 QRE121J-271Y C R 270¸ 1/2W J
R8817 NRSA63J-102X MG R 1k¸ 1/16W J
R8818 NRSA63J-102X MG R 1k¸ 1/16W J
R8819 NRSA63J-272X MG R 2.7k¸ 1/16W J
R8826 NRSA63J-0R0X MG R 0.0¸ 1/16W J
R8830 NRSA63J-222X MG R 2.2k¸ 1/16W J
R8831 NRSA63J-222X MG R 2.2k¸ 1/16W J
! R8901 QRZ0111-474 C R 470k¸ 1W K
CAPACITOR
C8481 NCB21EK-224X C CAP. 0.22µF 25V K
C8482 NCB21EK-224X C CAP. 0.22µF 25V K
C8483 NCB21EK-224X C CAP. 0.22µF 25V K
C8484 NCB21EK-224X C CAP. 0.22µF 25V K
C8485 QETN1EM-476Z E CAP. 47µF 25V M
C8487 QFLC1HJ-103Z M CAP. 0.01µF 50V J
C8660 QETM1VM-108 E CAP. 1000µF 35V M
C8661 QETM1VM-108 E CAP. 1000µF 35V M
C8801 QETN1HM-106Z E CAP. 10µF 50V M
C8802 QETN1CM-107Z E CAP. 100µF 16V M
C8803 NCB31CK-104X C CAP. 0.1µF 16V K
C8815 QETN1CM-107Z E CAP. 100µF 16V M
! C8901 QFZ9072-224 MM CAP. 0.22µF
COIL
L8401 QQL244K-820Z COIL 82µHK
DIODE
D8801 MA111-X SI. DIODE
D8802 P1241-04 PHOTO CONDUCTOR
D8803 SLR-342VR-T16 LED
TRANSISTOR
Q8481 2SC2412K/QR/-X TRANSISTOR
Q8801 2SA1037AK/QR/-X TRANSISTOR
