1-2 (No.YA445)
SPECIFICATION
Design and specifications subject to change without notice.
Items
Contents
AV-25MS16/H AV-25MX16/G AV-25MX16/S AV-25MX56/S
Dimensions (W × H × D) 72.8 cm × 53.6 cm × 47.7 cm
Mass 32 kg 30.5 kg
TV RF System B, G, I, D, K, M
Colour System PAL / SECAM / NTSC 3.58 / NTSC 4.43
Stereo System
A2 (B/G) / NICAM (B/G, I, D/K) Playback
Receiving
Frequency
VHF Low 46.25MHz - 140.25MHz (AS0 - S6)
VHF High 147.25MHz - 423.25MHz (S7 - S36)
UHF 431.25MHz - 863.25MHz (S37 - C57)
CATV Mid (X - Z+2, S1 - S10) / Super (S11 - S20) / Hyper (S21 - S41) bands
Intermediate
Frequency
VIF 38.0MHz (B, G, I, D, K, M)
SIF 32.26 MHz (5.74 MHz: B), 32.15MHz (5.85 MHz: G), 31.45 MHz (6.55 MHz: I)
31.75 MHz (6.5 MHz: D), 32.15MHz (5.85 MHz: K)
Colour Sub
Carrier
PAL 4.43 MHz
SECAM 4.40625 MHz / 4.25 MHz
NTSC 3.58 MHz / 4.43 MHz
Power Input AC110 V - AC240 V, 50 Hz/60 Hz
Power Consumption 137W (Max) /113W (Avg) 137W (Max) / 91W (Avg)
Picture Tube Visible size : 61.0 cm, Measured diagonally H: 48.6 cm × V: 36.8 cm
High Voltage 30.5 kV ±1.5 kV (at zero beam current)
Speaker 6.5 cm × 13 cm, oval type × 2
Audio Power Output 7 W + 7 W (Rated power output)
Aerial Input 75 Ω unbalanced, coaxial
Video / Audio
Input-1/2/3
Component Video
[VIDEO-2]
RCA pin jack × 3
Y:1V(p-p), positive (negative sync), 75Ω
Cb/Cr:0.7V(p-p), 75Ω
S-Video
[VIDEO-1]
Mini-DIN 4 pin × 1
Y: 1V(p-p), positive (negative sync provided), 75Ω
C: 0.286V(p-p) (Burst signal), 75Ω
Video 1V(p-p), negative sync, 75Ω, RCA pin jack × 3
Audio 500mV(rms) (-4dBs), high impedance, RCA pin jack × 6
Video / Audio
Output
Video 1V(p-p), 75Ω, RCA pin jack × 1
Audio 500mV(rms)(-4dBs), Low impedance, RCA pin jack × 2
Headphone jack 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C1286 (UM-3/AA/R6 dry cell battery × 2)
RM-C1285 (UM-3/AA/R6 dry cell battery × 2)
