JVC AV-28BD5EKI - Specifications

No.51709
A
V-28BD5EKI AV-28BD5EP AV-28BD5EE
A
V-28BD5EKIS AV-28BD5EPS AV-28BD5EES
1-2
SPECIFICATIONS
Item Content
TV RF SYSTEM
B/G, I, D/K & L/L’
COLOUR STANDARD
PAL / SECAM / NTSC (AV only)
POWER INPUT
AC 230V, 50Hz
POWER CONSUMPTION
75W / 3W (STBY)
TELETEXT SYSTEM
FLOF (Fastext) / TOP / WST (standard system)
SOUND OUTPUT / SPEAKER
7W / 8
Ω
(
×
2)
PICTURE TUBE SIZE
VISIBLE AREA 66cm (measured diagonally)
ANTENNA INPUT
75
Ω
Unbalanced
FRONT: RCA JACK (VIDEO / AUDIO)
INPUT / OUTPUT
REAR : 21-PIN EURO CONNECTOR (SCART)
×
2
(VIDEO / AUDIO / RGB / S. VHS)
INTERMEDIATE FREQUENCIES
PIF : 38.9MHz (B/G, D/K, I, L) , 33.9MHz (L’)
SIF : 33.4MHz (PAL / SECAM – B/G)
32.9MHz (PAL / SECAM – I / I)
32.4MHz (PAL / SECAM – D/K, SECAM – L)
40.4MHz (SECAM – L’)
SOUND SUBCARRIER : 5.5MHz (PAL / SECAM – B/G)
6.0MHz (PAL / SECAM – I / I)
6.5MHz (PAL / SECAM – D/K, SECAM – L)
6.5MHz (SECAM – L’)
COLOUR SUBCARRIER : 4.43MHz (PAL)
4.250MHz, 4.406MHz (SECAM)
REMOTE CONTROL
RM-C71 [ Batt, AAA (R03) ] (EP, EPS, EE, EES)
RM-C72 [ Batt, AAA (R03) ] (EKI, EKIS)
DIMENSIONS (W
×
××
×
H
×
××
×
D)
760mm
×
589mm
×
475mm
MASS
32kg
Design & specifications are subject to change without notice
.
COMMON INPUT
