1-2 (No.YA263)
SPECIFICATION
Design & specifications are subject to change without notice.
Items
Contents
AV-28H5BU
AV-28H5BL
AV-28H5SU
AV-28H5SL
AV-28H50SU
AV-28H5SK
AV-28H5SR
Dimensions ( W × H × D ) 76.2 cm × 52.8 cm × 49.2 cm 85.4 cm × 50.8 cm × 49.0 cm 76.2 cm × 52.8 cm × 49.2 cm
Mass 38.0 kg 39.0 kg 38.0 kg
TV RF System CCIR (B/G, I, D/K, L) CCIR (I)
Colour System PAL
SECAM
NTSC3.58 / NTSC4.43 (Only EXT mode)
PAL
NTSC3.58 / NTSC4.43 (Only EXT mode)
Stereo System A2 (B/G, D/K)
NICAM (B/G, I, D/K, L)
NICAM (I)
Receiving
Frequency
VHF 47 MHz - 470 MHz [Except AV-28H5SK]
UHF 470 MHz - 862 MHz
French CATV 116 MHz - 172 MHz
220 MHz - 469 MHz
---
Intermediate
Frequency
VIF 38.9 MHz (B/G, I, D/K, L) 38.9 MHz (I)
SIF 33.4 MHz (5.5 MHz :B/G)
32.9 MHz ( 6.0 MHz:I )
32.4 MHz (6.5 MHz :L, D/K)
32.9 MHz ( 6.0 MHz:I )
Colour Sub
Carrier Frequency
PAL 4.43 MHz
SECAM 4.40625 MHz / 4.25 MHz ---
NTSC 3.58 MHz / 4.43 MHz
Teletext System TOP (German system)
FLOF (Fastext)
WST (Standard system)
Power Input AC220 V - AC240 V, 50 Hz
Power Consumption 120 W, Standby : 0.6 W 120 W, Standby : 2.5 W 120 W, Standby : 0.6 W
Picture Tube Visible size : 66 cm [measured diagonally (H : 58.3 cm × V : 33.0 cm)
High Voltage 31.0 kV (+1 kV / -1.5 kV) (at zero beam current)
Speaker 13 cm × 6.5 cm oval type × 2
Audio Power Output 10 W + 10 W
Aerial Input Terminal 75 Ω unbalanced, coaxial
EXT-1 / EXT-2 / EXT-3
(Input / Output)
21-pin Euro connector (SCART socket × 3)
EXT-4 (Input) S-Video
Video
Audio (L/R)
Mini-Din 4 pin × 1
Y : 1 V(p-p) positive (negative sync, 75Ω)
C : 0.3 V(p-p) (Burst signal, 75Ω)
1 V(p-p) 75 Ω, RCA pin jack × 1
500 mV(rms) (-4 dBs), High impedance, RCA pin jack × 2
Audio output 0-1000 mV (rms), Low impedance, RCA pin jack × 2
Headphone Jack 3.5 mm stereo mini jack × 1
Remote Control Unit
RM-C1502 (AA/R6 dry cell battery
×
2) [AV-28H5SU/AV-28H5SL/AV-28H5SK/AV-28H5SR/AV-28H50SU]
RM-C1502B (AA/R6 dry cell battery
×
2) [AV-28H5BU/AV-28H5BL]
