JVC AV-29LS24

1-4 (No.YA105D)
Ref. No.
Part No.
PART NAME DESCRIPTIONAV-29LX14/S [SCW-1017A-H2]
BEFORE AFTER
IC451 UPC358G2-XE --- IC Delete
Q461 2SD1267A/QP/ RDN050N20 POW TRANSISTOR
D451 MA8043/L/-X --- Z DIODE Delete
C452 QETN1HM-226Z --- E CAPACITOR Delete
C453 QETN1HM-106Z --- E CAPACITOR Delete
R451 QRE121J-681Y --- C RESISTOR Delete
R452 NRSA63J-272X NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R453 NRSA63J-223X --- MG RESISTOR Delete
R454 NRSA63J-562X --- MG RESISTOR Delete
R455 NRSA63J-123X NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R456 NRSA63J-562X --- MG RESISTOR Delete
R457 NRSA63J-823X --- MG RESISTOR Delete
R458 NRSA63J-333X NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R459 NRSA63J-822X --- MG RESISTOR Delete
R460 QRE121J-223Y QRE121J-823Y C RESISTOR 82kΩ 1/2W J
R461 NRSA63J-562X --- MG RESISTOR Delete
R462 NRSA63J-122X NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R463 NRSA63J-102X --- MG RESISTOR Delete
R470 --- NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Ref. No.
Part No.
PART NAME DESCRIPTIONAV-29LS24/N [SCW-1109A-H2]
BEFORE AFTER
IC451 UPC358G2-XE --- IC Delete
Q461 2SD1267A/QP/ RDN050N20 POW TRANSISTOR
D451 MA8043/L/-X --- Z DIODE Delete
C452 QETN1HM-226Z --- E CAPACITOR Delete
C453 QETN1HM-106Z --- E CAPACITOR Delete
R451 QRE121J-681Y --- C RESISTOR Delete
R452 NRSA63J-272X NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R453 NRSA63J-223X --- MG RESISTOR Delete
R454 NRSA63J-562X --- MG RESISTOR Delete
R455 NRSA63J-123X NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R456 NRSA63J-562X --- MG RESISTOR Delete
R457 NRSA63J-823X --- MG RESISTOR Delete
R458 NRSA63J-333X NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R459 NRSA63J-822X --- MG RESISTOR Delete
R460 QRE121J-223Y QRE121J-823Y C RESISTOR 82kΩ 1/2W J
R461 NRSA63J-562X --- MG RESISTOR Delete
R462 NRSA63J-122X NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R463 NRSA63J-102X --- MG RESISTOR Delete
R470 --- NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
