2No. 52061
AV-29WS3 AV-29WX3
AV-29WH3 AV-2978TEE
Dimensions (W × H × D)
81.2cm x 58.42cm x 51.8cm
Mass 45kg
TV RF System B, G, I, D, K, K1, M
Colour System TV Mode PAL / SECAM / NTSC3.58 / NTSC4.43
VIDEO Mode PAL / SECAM / NTSC3.58 / NTSC4.43
Stereo System A2/NICAM (B / G, I, D / K) System Playback Only
Teletext system
FLOF(Fastext), Q — Q
WST(World Standard Text)
Receiving Frequency VHF (VL) 46.25MHz – 140.25MHz (AS0 – S6)
VHF (VH) 147.25MHz – 423.25MHz (S7 – S36)
UHF 431.25MHz – 863.25MHz (S37 – CHINA 57)
CATV ● Cable TVs of Mid (X-Z, S1-S10)
Super (S11-S20) & Hyper (S21-S41) bands receivable
Intermediate VIF Carrier 38.0MHz
Frequency 31.5MHz (6.5MHz)
SIF Carrier 32.0MHz (6.0MHz)
32.5MHz (5.5MHz)
33.5MHz (4.5MHz)
Colour Sub Carrier Frequency PAL (4.43MHz), SECAM (4.40625MHz / 4.25MHz)
NTSC (3.58MHz / 4.43MHz)
Aerial Input Terminal 75Ø Unbalanced
Power Input AC110 – 240V, 50 / 60Hz
Power Consumption 175W
(Max.)
/ 116W
(Avg.)
Picture Tube Visible size : 68cm measured diagonally
High Voltage 32kV+1/ –1.5kV (at cut-off in service mode)
Speaker 6.5 × 13cm Oval type × 2
Audio Output 7W + 7W
Video / Audio Input (1 / 2 / 3) Video(1,3) : 1Vp-p, 75Ø (RCA pin jack)
Audio(1,2,3) : 500mVrms ( -4dBs ), High Impedance (RCA pin jack)
S-Video ( Input 1 Over ) [Only for AV-29WS3/AU, AV-29WH3]
Y:1Vp-p Positive (negative sync provided, when terminated with 75Ø)
C:0.286Vp-p (burst signal, when terminated with 75Ø)
Component Input ( Input 2 )
Y:1Vp-p positive (negative sync provided, when terminated with 75Ø)
CB/CR : 0.7Vp-p 75Ø
Video/ Audio Output 1Vp-p, 75Ø (RCA pin jack)
500mVrms(-4dBs)
Low impedance (400Hz when modulated 100%) (RCA pin jack)
Headphone Jack Stereo mini jack (3.5φ)
Remote Control Unit RM-C1010-1H
RM-C1011-1H
RM-C1014-1H RM-C1013-1H
(Battery size: AA/R06/UM-3 × 2)
SPECIFICATIONS
Items
Design & specifications are subject to change without notice.
Contents
AV-29WS3
AV-29WS3
/AU AV-29WH3 AV-29WX3 AV-29WX3/A AV-2978TEE
